FPS SDH Series
SDL Series is a compact drainage pump designed for demanding dewatering tasks in residential, construction, industrial and mining environments. The pump comes with top discharge making it ideal to install at space constraint place. The pump is equipped with semi open impeller, suitable to remove rainwater, pondwater and high viscosity fluid such as muddy water.
FEATURES
- Robust design, high performance and easy to maintain.
Motor incorporates built-in protection (Models 11kW and below) to prevent motor failure due to overloading and phase loss, etc - Double mechanical seals made of high-quality material providing high level of protection against leakage.
- High chrome alloy impeller increases wear resistance to abrasion.
SPECIFICATION
- Flow up to 156m³/hr, head up to 56m
- Maximum water depth: 25m
- Working water temperature: up to 400C
- Motor: Class F, IP68
Performance Curves Table - SDH
Model
Outlet
Motor
Power
Rated Current (400V)
Rated Capacity
Rated Head
Max. Capacity
Max Head
Impeller Passage
mm
kW
HP
A
m³/h
m³/min
m
m³/h
m³/min
m
mm
50SDH-2-1.5-T
50
1.5
2
3.5
15
0.25
15
27
0.45
22
8.5
50SDH-2-2.2-T
50
2.2
3
5.0
18
0.30
20
33
0.55
26
8.5
50SDH-2-3.7-T
50
3.7
5
7.7
12
0.2
30
33
0.55
34
8.5
80SDH-2-1.5-M
80
1.5
2
3.5
30
0.50
8
40
0.67
14.5
8.5
80SDH-2-2.2-T
80
2.2
3
5.0
36
0.6
11
55
0.92
19
8.5
80SDH-2-3.7-T
80
3.7
5
7.7
30
0.5
20
55
0.92
29
8.5
80SDH-2-5.5-T
80
5.5
7.5
11.4
36
0.6
25
75
1.25
34
8.5
100SDH-2-3.7-T
100
3.7
5
7.7
60
1
11.5
90
1.5
18.5
8.5
100SDH-2-5.5-T
100
5.5
7.5
11.4
60
1
16
105
1.75
23
8.5
100SDH-2-7.5-T
100
7.5
10
15
48
0.8
30
84
1.4
40
11.5
100SDH-2-11-T
100
11
15
22
60
1
35
84
1.4
48.5
11.5
100SDH-2-15-T
100
15
20
29.5
60
1
42
84
1.4
56
11.5
150SDH-2-7.5-T
150
7.5
10
15
90
1.6
15
124.8
2.08
31
19.5
150SDH-2-11-T
150
11
15
22
102
1.7
22
147
2.45
32
19.5
150SDH-2-15-T
150
15
20
29.5
102
1.7
30
156
2.6
40
19.5
| Model | Outlet | Motor Power | Rated Current (400V) | Rated Capacity | Rated Head | Max. Capacity | Max Head | Impeller Passage | |||
| mm | kW | HP | A | m³/h | m³/min | m | m³/h | m³/min | m | mm | |
| 50SDH-2-1.5-T | 50 | 1.5 | 2 | 3.5 | 15 | 0.25 | 15 | 27 | 0.45 | 22 | 8.5 |
| 50SDH-2-2.2-T | 50 | 2.2 | 3 | 5.0 | 18 | 0.30 | 20 | 33 | 0.55 | 26 | 8.5 |
| 50SDH-2-3.7-T | 50 | 3.7 | 5 | 7.7 | 12 | 0.2 | 30 | 33 | 0.55 | 34 | 8.5 |
| 80SDH-2-1.5-M | 80 | 1.5 | 2 | 3.5 | 30 | 0.50 | 8 | 40 | 0.67 | 14.5 | 8.5 |
| 80SDH-2-2.2-T | 80 | 2.2 | 3 | 5.0 | 36 | 0.6 | 11 | 55 | 0.92 | 19 | 8.5 |
| 80SDH-2-3.7-T | 80 | 3.7 | 5 | 7.7 | 30 | 0.5 | 20 | 55 | 0.92 | 29 | 8.5 |
| 80SDH-2-5.5-T | 80 | 5.5 | 7.5 | 11.4 | 36 | 0.6 | 25 | 75 | 1.25 | 34 | 8.5 |
| 100SDH-2-3.7-T | 100 | 3.7 | 5 | 7.7 | 60 | 1 | 11.5 | 90 | 1.5 | 18.5 | 8.5 |
| 100SDH-2-5.5-T | 100 | 5.5 | 7.5 | 11.4 | 60 | 1 | 16 | 105 | 1.75 | 23 | 8.5 |
| 100SDH-2-7.5-T | 100 | 7.5 | 10 | 15 | 48 | 0.8 | 30 | 84 | 1.4 | 40 | 11.5 |
| 100SDH-2-11-T | 100 | 11 | 15 | 22 | 60 | 1 | 35 | 84 | 1.4 | 48.5 | 11.5 |
| 100SDH-2-15-T | 100 | 15 | 20 | 29.5 | 60 | 1 | 42 | 84 | 1.4 | 56 | 11.5 |
| 150SDH-2-7.5-T | 150 | 7.5 | 10 | 15 | 90 | 1.6 | 15 | 124.8 | 2.08 | 31 | 19.5 |
| 150SDH-2-11-T | 150 | 11 | 15 | 22 | 102 | 1.7 | 22 | 147 | 2.45 | 32 | 19.5 |
| 150SDH-2-15-T | 150 | 15 | 20 | 29.5 | 102 | 1.7 | 30 | 156 | 2.6 | 40 | 19.5 |
40FDR 50 Hz
| Pump model | Phase | Q = Delivery | |||||||||||
| l/sec 0 | 0,5 | 1 | 1,5 | 2 | 2,5 | 3 | 3,5 | 4 | 4,5 | 5 | 5,5 | ||
| m³/h 0 | 1,8 | 3,6 | 5,4 | 7,2 | 9 | 10,8 | 12,6 | 14,4 | 16,2 | 18 | 19,8 | ||
| US gpm 0 | 7,9 | 15,8 | 23,7 | 31,7 | 39,6 | 47,5 | 55,5 | 63,4 | 71,3 | 79,2 | 87,2 | ||
| H = Total meters head of water column [m] | |||||||||||||
| 40FDR-52-0,37 | 1 ~ | 8 | 7,6 | 7,1 | 6,5 | 5,6 | 4,5 | 4 | 3 | 2 | |||
| 40FDR-52-0,6 | 1 ~ | 8,9 | 8,2 | 8 | 7,1 | 6,8 | 6 | 5,4 | 4,5 | 3,8 | 2,8 | 2 | |
| 40FDR-52-0,7 | 1 ~ | 11 | 10,8 | 10,5 | 9,9 | 9,4 | 8,8 | 8,2 | 7,4 | 6,5 | 5,4 | 4,1 | 2,4 |
| 3 ~ | 11 | 10,8 | 10,5 | 9,9 | 9,4 | 8,8 | 8,2 | 7,4 | 6,5 | 5,4 | 4,1 | 2,4 | |
50FDR 50 Hz
| Pump model | Phase | Q = Delivery | ||||||||||||||
| l/sec 0 | 1 | 1,5 | 2 | 2,5 | 3 | 3,5 | 4 | 4,5 | 5 | 6 | 7 | 8 | 9 | 10 | ||
| m³/h 0 | 3,6 | 5,4 | 7,2 | 9 | 10,8 | 12,6 | 14,4 | 16,2 | 18 | 21,6 | 25,2 | 28,8 | 32,4 | 36 | ||
| US gpm 0 | 15,8 | 23,7 | 31,7 | 39,6 | 47,5 | 55,5 | 63,4 | 71,3 | 79,2 | 92,1 | 110,9 | 126,8 | 142,6 | 158,5 | ||
| H = Total meters head of water column [m] | ||||||||||||||||
| 50FDR-52-0,9 | 1 ~ | 14,8 | 14 | 13,5 | 13,2 | 12,5 | 12 | 11,1 | 10,6 | 9,7 | 8,7 | 7,2 | 4,7 | 2,5 | ||
| 3 ~ | 14,8 | 14 | 13,5 | 13,2 | 12,5 | 12 | 11,1 | 10,6 | 9,7 | 8,7 | 7,2 | 4,7 | 2,5 | |||
| 50FDR-52-1,4 | 1 ~ | 18 | 17,7 | 17,5 | 17,2 | 16,6 | 16,4 | 15,9 | 15,5 | 14,2 | 14 | 12,8 | 10,5 | 9 | 6,8 | 4,2 |
| 3 ~ | 18 | 17,7 | 17,5 | 17,2 | 16,6 | 16,4 | 15,9 | 15,5 | 14,2 | 14 | 12,8 | 10,5 | 9 | 6,8 | 4,2 | |
